1) External dimension: L7M*W7.4M*H9.9M (L23’*W24’3″*H32’6″)
Internal dimension:L6M*W6.5M*H2.5M (L19’8″*W21’4″*H8’2″)
Indoor area: 105.6㎡ (1137sq.ft) Balcony area: 11.4㎡ (123sq.ft)
2) Cabin weight: 15400kgs
3) Steel structure: square tube (thickness: 3mm)
4) Partition wall: steel sheet
5) Wall: EPS Sandwich Panel/Rock wool board panel (thickness: 75mm)
6) Floor: Steel Sheet(3mm) & base Fiber Cement Board 18mm+carpets 15mm for all flooring area.
7) Roof: Steel Sheet(3mm) & EPS Sandwich thickness (50mm)
8) Windows: Aluminum alloy window frame+(6mm+12A+6mm) Double layer glazed LOW E tempered glass
9) Doors: Steel door/Glass door
10) Wind resistant: 0.6kN/㎡
11) Earthquake resistance: 7 grade
12) Fireproof: A calss /120 Mins
13) Floor load capacity: 3kN/㎡
14) Life span: 50 years
15.) Unit of loading into a 40 feet HQ container: 0.8 sets
